중간 전압 개폐 장치용 10kv 내장형 극 인출 진공 회로 차단기

기본정보

모델 번호.	ZN83-12KV
아크 소화 매체	진공
설치	끼워 넣다
구조	ACB
극수	삼
유형	회로 차단기
기능	기존 차단기, 차단기 고장 보호, 과전류 보호, OVP(과전압 보호), 손수레/고정형
인증	ISO9001-2000, CCC
정격 단락 차단 전류	20~40ka
기계적 수명	10000
작동 전압	AC/DC110/220V
캐비닛 너비	650/800/1000mm
정격 전류	630~4000A
운송 패키지	합판 케이스
사양	0.5m3
등록 상표	VACEM
기원	중국 원저우
HS 코드	85352100
생산 능력	20000PCS/년

포장 및 배송

패키지 크기 70.00cm * 70.00cm * 75.00cm 패키지 총중량 110.000kg 리드타임 7일 (1 - 1개)
100 Pieces) br h5Product Description/h5 1. General description ZN83 VCB vacuum circuit breaker is a new type of indoor medium voltage switch device, which is mainly used in a three-phase AC power system with a rated voltage of 12kv, and a rated frequency of 50-60Hz. It has the advantages of a compact structure, high reliability, small operation vibration and easy maintenance. It can be widely used in power plants, steel plants, metallurgy, petrochemical, transportation, building and other industrial and mining enterprises as a switch device for protection of high voltage motors, transformers,line faults and other loads.br strong2. Product characteristic /strongTaking different functional units as the dividing line to realize the modular design. The integrated and optimized design minimizes the intermediate realization link of the functional unit, and the overall mechanism only has more than 70 parts.br There is no adjustment link in the mechanism to minimize the professional requirements for maintenance personnel.br The whole series of products are easy to operate.br Small mechanical operation vibration.br Mechanism with manual energy storage handle.br Fast replacement of wearing parts without special tools.br The whole series of mechanisms have passed the verification of 72 hour salt spray test.br strong3.Simple and reliable structure/strong>
